Features

1.Various furnace bodies can be customized to meet the heating needs of various heated materials (magnetic permeability);
2.Temperature adjustment function: adapt to different production speed, different moisture content of the sealant and a variety of temperature, humidity working environment;
3.Temperature sensing and display function；
4.Hot air insulation and dehumidification function；
5.Temperature beyond the set range automatic alarm function, and can be interlocking control with other equipment in the production line.

Parameters

Speed	150-1000pcs
Equipment size(L×W×H)	1850*450*1500 (Single channel)1850*630*1500 (dual channel)
Applied voltage / power	AC380V±10% T-C-S power supply 2KW/ channel
Scope of application	Top / bottom of various aerosol cans with diameter of Ф 45 - Ф 99 mm
Working system	Continuous duty
Gas supply pressure	5- 8kg/cm²
Operation mode	Fully automatic/Chinese/English display/touch panel
Control method	PLC/inverter, touch screen operation, automatic operation, automatic reset
Equipment safety protection	Complete electrical protection, over temperature protection
