Features

1.Mold material selection of high-quality die steel, multi-station design;
2.Design and manufacture molds according to customers' needs, and implement various programs;
3.The cam-type feeding mechanism can accurately feed the foundation cover into the multi-station mold;
4.Base cover split cover system, multi-channel automatic conversion into two channels;
5.According to the cover stock of the base cover conveying line, the stamping speed of the multi-station punch is automatically adjusted to make the whole production line run coherently and stably;
6.The injection machine with independent intellectual property rights can automatically adjust the injection speed according to the number of injection caps;
7.The visual inspection system with independent intellectual property rights can accurately eliminate unqualified covers and prevent unqualified products from flowing into the canning process;
8.Improve inspection efficiency, improve product quality, improve yield, reduce the amount of waste;
9.Independent intellectual property counting packaging system, automatic counting, automatic bag, reduce labor costs.

 Parameters

Model	JFAT-400
Production speed	400 PCS/min
Size(LxWxH)	21000*3650*2250 mm
Applied voltage / power	AC380 ± 10%、T-C-S Power Supply  27KW
Working system	24-hour continuous working system
Gas supply pressure	0 .5-0 .8MPa
Operation mode	Full automatic / Chinese and English display / touch panel
Control method	PLC, frequency converter, touch screen control,automatic operation, automatic reset
Packing count accuracy	±1 pcs
Equipment safety protection	Safety grating protection, equipment operation fault protection, all electrical protection
