Features

1.Mold material selection of high-quality die steel, multi-station design;
2.We can design and manufacture molds according to customers' needs and implement various programs;
3.The cam-type feeding mechanism can accurately feed the foundation cover into the multi-station mold;
4.Base cover system, multi-channel automatically converted into two channels;
5.According to the cover stock of the base cover conveying line, the stamping speed of the multi-station punch is automatically adjusted to make the whole production line run smoothly and stably;
6.The glue machine with independent intellectual property rights can automatically adjust the glue filling speed according to the amount of glue filling cover;
7.The visual inspection system with independent intellectual property rights can accurately eliminate unqualified covers and prevent unqualified products from flowing into the canning process;
8.Independent intellectual property counting packaging system, automatic counting, automatic bag, reduce labor costs.

 Parameters

Model	JFAT-300
Production speed	300 pcs per min
Size (L×W×H)	21000*3650*2250 mm
Applied voltage / power	AC380 ± 10%、T-C-S  Power  Supply  27KW
Working system	24-hour continuous working system
Gas supply pressure	0 .5-0 .8MPa
Operation mode	Full automatic / Chinese and English display / touch panel
Control method	PLC, frequency converter, touch screen control,automatic operation, automatic reset
Packing count accuracy	±1 pcs
Equipment safety protection	Safety grating protection, equipment operation fault protection, all electrical protection
