Features

1.Automatic loading and feeding without manual operation.
2.Chinese and English display, touch screen operation, parameter setting and data display at a glance.
3.Power off data automatic memory, power on automatic recovery work.
4.The system can be moved, semi-automatic, fully automatic work, automatic zero.
5.Reserve the punch die protection function and interface, and install the corresponding sensor to prevent stamping heavy material.

 Parameters

Model specification	JFF-CNL-180
Machine size(L×W×H)	3400* 2150* 1700mm
Machine weight	1000Kg
Voltage	AC380V±10% T-C-S Power Supply
Power	6.3KW
Working system	Continuous working system
Production efficiency	Adjustable speed
Gas supply pressure	0.5-0.8MPa
Operation mode	Full automatic / Chinese and English display / touch panel
Control method	PLC, frequency converter, stepless speed regulation, automatic number memory, automatic reset
Maximum running range for before and after of the screw rod	1200mm
Maximum running range left and right travel of the crew rod	1200mm
Lifting platform	Minimum height of roller surface * stroke: 530 * 400mm
