Features

1.Design and manufacture molds according to customers' needs, implement various design schemes;
2.Mold material selection of high-quality die steel, multi-station design;
3.The CAM synchronous feeding mechanism can accurately send the foundation cover to the multi-station mold;
4.Comprehensive automated security inspection;
5.Program with parameter setting, modular design.

 Parameters

Model	JFBL-120/280
Production speed	Single channel,80~120pcs per min .Double channel,200~280pcs per min .
Applied voltage / power	AC380V±10% ，T-C-S Power Supply/12KW
Working system	24-hour continuous working system
Gas Supply Pressure	0 .5-0 .8MPa
Operation mode	Full automatic / Chinese and English display / touch panel
Control method	PLC, frequency converter, touch screen control,automatic operation, automatic reset
Equipment safety protection	Safety grating protection, equipment operation fault protection, all electrical protection
