Features

1.Design and manufacture molds according to customers' needs, and implement various programs;
2.According to the number of conveyor covers, automatically adjust the speed of the multi-station press, so that the whole production line runs continuously and stably;
3.Mold material selection of high-quality die steel, multi-station design;
4.The cam-type feeding mechanism can accurately feed the foundation cover into the multi-station mold;
5.The patent of multi-station feeding mechanism makes the production process more stable;
6.Glue machine with independent intellectual property rights: adjustable glue injection time and amount, can automatically adjust the glue injection speed according to the amount of storage cap;
7.The cover defect visual detection system with independent intellectual property rights can accurately remove unqualified covers;
8.Counting and packaging system with independent intellectual property rights: automatic counting, automatic bagging, reducing the labor intensity of workers.

 Parameters

Model	JFAL-120
Production speed	100~120pc s per m in
Applied voltage / power	AC360~400V , Three phase five wire system , 18KW
Size(LxWxH)	1700*3650*2250mm
Working system	24-hour continuous working system
Gas supply pressure	0 .5-0 .8MPa
Operation mode	Full automatic / Chinese and English display / touch panel
Control method	PLC, frequency converter, touch screen control,automatic operation, automatic reset
Packing count accuracy	± 1 pcs
Equipment safety protection	Safety grating protection, equipment operation fault protection, all electrical protection
